Product Details
Place of Origin: Fujian, China
Brand Name: AFP
Certification: SGS, BV,
Model Number: POF Heat Shrink Wrapping Film
Payment & Shipping Terms
Minimum Order Quantity: 1 Ton (1,000kgs)/Trial Order Negotiable
Price: USD2118.00/Ton ~ USD2380.00/Ton
Packaging Details: 1-Each roll of pof heat shrink film, one carton; 2-Tens of cartons pack into a pallet; 3-10 ~ 12pallets pack into 1*20 ft. container; 4-or 20~22 pallets load into 1*40 ft. container
Delivery Time: 15 - 25 working days a 40GP
Payment Terms: T/T, L/C, Western Union
Supply Ability: 350 tons per month
Material: |
PP + PE |
Type: |
POF Shrink Film Center-folded, Single Wound, Tube And Bags |
Softness: |
Soft |
Thickness: |
12.5micron, 15micron, 19micron, 25micron |
Transparency: |
Transparent |
Roll Width: |
200mm (8") To 1600mm (80") |
Shrinkage Ratio: |
Over 60% |
Roll Length: |
1600m To 3200m Of Single Wound, 800m To 1600m Of Center-folded |
Processing Technology: |
5 Layer Co-extruded Polyolefin Shrink Film |
Usage: |
Heat Shrink Wrapping Film For Book And Food Packaging |
Material: |
PP + PE |
Type: |
POF Shrink Film Center-folded, Single Wound, Tube And Bags |
Softness: |
Soft |
Thickness: |
12.5micron, 15micron, 19micron, 25micron |
Transparency: |
Transparent |
Roll Width: |
200mm (8") To 1600mm (80") |
Shrinkage Ratio: |
Over 60% |
Roll Length: |
1600m To 3200m Of Single Wound, 800m To 1600m Of Center-folded |
Processing Technology: |
5 Layer Co-extruded Polyolefin Shrink Film |
Usage: |
Heat Shrink Wrapping Film For Book And Food Packaging |
High Shrinkage POF Wrap Film Polyolefin Shrink Film, 12.5micron 15micron 19micron 25micron
Product Name: Polyolefin POF Heat Shrink Wrap Film
Material: PP + PE
Shrinkage ratio: over 60%
Thickness: 12.5micron (50gauge), 15micron (60gauge), 19micron (75gauga), 25micron (100gauge)
Minimum Order Quantity: 2,000kgs (multi roll width within an order available)
Roll width: 200mm (8") to 1600mm (80")
Roll length: 800m to 1600m for center-folded, 1600m to 3200m for single wound
for standard sizes, please refer to the SPECIFICATIONS below
Type: single wound, corner folded (also called center-folded,), tube
Polyolefin POF Heat Shrink Wrap Film is now the most widely used shrink packaging materials due to being cost effective, strong, shape conforming and tamper evident.
it is clear, elastic and has a smooth texture.
it is composted of Polypropylene (PP) and Polyethylene (PE) which are non-toxic and non-smelly.
this product is environmentally friendly, approved by FDA for direct food contact
it can protect your products efficiently and doesn’t emit harmful gas during usage.
it is a strong and high clarity biaxial oriented heat shrinkable film that has stable & balanced shrinkage and soft corner during packaging.
Center-folded polyolefin shrink wrap film is a great option for packaging a variety of products.
Companies have moved to using polyolefin to package everything from consumable products to bundling insect sprays.
The film is folded length ways onto the roll to allow users to quickly insert the product being packaged into the fold crease.
Once the product is placed into the fold crease, film will be covering the product on both sides.
Matched Packaging Machine for POF Shrink Wrap Film
*Side sealer continuous motion
*Side sealer intermittent motion
*Automatic L-bar sealer
*Semi-automatic L-bar Sealer
*Vertical L-bar Sealer
*2 in 1 shrink wrapper
Applications
*Suitable for all types of food, chemical products, hardwares, soap, sport equipment, books and magzines etc.
*Used to regular and irregular shape products like cups, stationery, toys, cosmetics, drinking tins, bottles.
Features
Our Polyolefin POF Shrink Wrap Film has features as below:
*excellent seal strength
*high shinkage ration over 60%
*high transparency and fine luster
*moderate air barrier property
*flexible tenacity and hermetic sealling property
*cold resistance
*soft and non-brittle
*damp-proof and anti-static
*fine heat sealing performance
Advantages of POF Shrink Film versus others
| Film Types | POF | PP | BOPP | PE | PVC |
| Price Ranking | 2nd | 1st | 3rd | 4th | 5th |
| Thickness | 10 - 30 | 15- 40 | 12 - 32 | 30 - 150 | 20 - 60 |
| Density Density(kg/m3) | 0.92 | 0.91 | 0.91 | 0.91 | 1.34 |
Specifications
| Standard POF Shrink Film | ||||||
| Property | Unit | Test Method | Representative Value | |||
|
Physical Property |
||||||
|
Thickness |
Micron | 12.5micron | 15micron | 19micron | 25micron | |
| Gauge | 50gauge | 60gauge | 75gauge | 100gauge | ||
| Density |
g/cm³ |
0.922 | 0.922 | 0.922 | 0.922 | |
| Tensile Property (MD/TD) | ||||||
| Elastic Mouduls |
N/mm² |
ASTM-D882A | 330/450 | 340/450 | 350/450 | 360/450 |
| Tensile Strength | MPa | ASTM-882 | 110/110 | 110/110 | 110/110 | 105/105 |
| Elongation at Break | % | ASTM-882 | 105/110 | 105/110 | 110/110 | 110/115 |
| Seal Strength | g/cm³ |
Internal Method |
610 | 870 | 1025 | 1250 |
| N/mm² | 40 | 57 | 53 | 49 | ||
| Tear Propagation | g/cm³ | ASTM-D1938 | 6 | 5.5 | 9.5 | 14.5 |
| COF film to film | Adim | ASTM-D1894 | 0.2 | 0.2 | 0.2 | 0.2 |
| Free Shrink at 130℃ | % | ASTM-D2732 | 70/70 | 70/70 | 70/70 | 70/70 |
| Optical Property | ||||||
| Haze | % | ASTM-D1003 | 1.1 | 1.3 | 1.8 | 2.3 |
| Gloss | % | ASTM-D2457 | 135 | 135 | 135 | 130 |
| Dimension Specification | ||||||
| Width | mm |
200--1600 (available to multi roll widths within an orde |
||||
| inch |
8" to 80" (available to multi roll widths within an order) |
|||||
| Length | S/W (single wound) | 3200m | 2665m | 2135m | 1600m | |
| 10500ft | 8750ft | 7000ft | 5250ft | |||
|
C/F (center-folded, corner folded) |
1600m | 1332m | 1067m | 800m | ||
| 5250ft | 4370ft | 3500ft | 2625ft | |||
You are able to place an order of Polyolefin POF Heat Shrink Wrap Film like this:
25micron (100gauge) Corner Folded (also called center-folded or cross linked)
12" (305mm) x 2625' (800m) x 100rolls (weight 1125.00kgs = 11.25kgs x 100rolls)
20" (508mm) x 2625' (800m) x 50rolls (weight 937.00kgs = 18.74kgs x 50rolls)
TOTALLY 150 rolls, 2,062.00kgs
Packaging & Shipping
*One roll Polyolefin POF Heat Shrink Wrap Film, one carton
*Approximately 60 cartons in a wooden pallet
*10 pallets in a 20FCL or 20 Pallets in a 40GP
*Seaport: Xiamen, Shanghai, Qingdao
FAQ
About Samples
*Samples for testing are available and free
*The freight for sample delivery is at receivers's side
*But to be refunded by deducting from the right coming order automatically
*For saving the cost, we recommend the way of prepaid instead of collect
About After-sale Service
* 9 months warranty
* In case of any quality problem happens, you must be equivalently compensated
Polyolefin Shrink Film Data Sheet.pdf
